DOUBLE EDGES GRINDING MACHINES

PRODUCTS > GLASS WORKING

ML-BG

CMV produces double edge grinding , single and online, with single or double transfer.
On each cross are assembled from two to six spindles, diamond and / or polishing.
The spindles are made in order to allow easy replacement of the grinding wheels, the transport system of the glass is realized with two brushless motors in electric axis, without mechanical connection organs , while the movement of the crosshead is realized on guides with recirculating ball, ball screw and a brushless motor.
The software is simple and intuitive, it allows to optimize production while reducing operator intervention and limiting the machine setting time .


PICTURE       LAYOUT     VIDEO                         BACK TO GRINDERS
